Multi-axis Screw Driving Machine
Request a Quote
The multi-axis screw driving machine can simultaneously process the products and improve the position repetition precision, suitable for larger electric products within 2000mm.
Advantages
- Double X axis, double Y axis, double platform and double work system. Each platform can independently work to achieve a maximum efficiency.
- Support coordinates import to track screw locking status in real time.
- Industrial computer control with unlimited storage capacity.
- Compatible with M0.8-M5 screws.
Parameters
| Model No. | 3-axis | 6-axis | 9-axis | 12-axis | |
| Outer dimensions | Customizable | ||||
| Movement range | X axis | 100mm-1500mm | |||
| Y axis | 300mm-500mm | ||||
| Z axis | 100mm-200mm | ||||
| Work platform | PLC control | ||||
| Speed range | 0.1~800mm/sec | ||||
| Position precision | ±0.02mm | ||||
| Repetition precision | ±0.02mm | ||||
| Drive method | Manual/automatic | ||||
| Work load | 30kg | ||||
| Drive method | Precision servo drive | ||||
| Control system | Industrial computer + motion control card | ||||
| Speed control | Automatic speed decrease and increase | ||||
| undefinedEfficiency of locking screws | 0.7-2s/PCS | ||||
| Electric screwdriver | Upon request | ||||
| Screw feeding | air input/air output (optional) | ||||
| Screw feeding speed | 60 screws/min | ||||
| Compatible screw diameter | M0.8-M5 | ||||
| Compatible screw types | Round head/ flat head/ counter sunk | ||||
| Compatible screw length | 5MM-16MM | ||||
| Compatible torque | 0.1~30kgf.cm | ||||
| Program storage capacity | Unlimited | ||||
| Communication port | USB/RS232 | ||||
| Operating temp. | 0℃~40℃ | ||||
| Operating humidity | 20~90% | ||||
| Air supply | 0.4~0.6Mpa | ||||
| Power supply | 220V.50HZ | ||||
| Weight | 350kg | ||||
| Automatic detections | Screw slippage detection | Yes | |||
| undefinedScrew missing detection | Yes | ||||
| Screw height detection | Yes | ||||
Applications
- Communication industry: mouse, smart phone, battery, tuner of different wavebands.
- LED industry: LED modules, LED panel, LED chip, LED ball lamp and etc.
- Household appliance industry: air conditioner remote control, TV enclosure, radio, sound and etc.
- Automobile industry: vehicle-mounted remote control, car gear shift knob, vehicle-mounted DVD player, etc.
- Toy industry: toy gun, toy handle and etc.
Professional non-standard custom-tailored solutions are provided by OKATA to meet screw locking requirements of hardware, plastic and wood products.
