Automotive Paint Booth, GL1-N Series
Request a Quote
GL1-N series automotive paint booth is a non-pitted paint booth offered in a standard configuration that includes exhaust fan and but excludes intake fan and heating system. It is typically used as sanding booth, primer booth and quick repair booth.
Specifications
- Exterior dimensions: 7.5×4.0×3.2m
- Interior dimensions: 6.9×3.9×2.7m
- Access door width: 3.0m
- Access door height: 2.66m
- Airflow: 18,000m 3 /h
- Air speed: 0.25-0.30 m/s
- Power: 7kw
- Applicable vehicle: sedan car
- Chinese standards or CE standards compliant (optional)
Standard Configurations
- Lighting system: upper lights are 8*4*18W LED light tubes, no lower lights;
- A tool cabinet and an electric control panel are integrated in to the rear wall of this paint booth. The tool cabinet is designed to add extra storage capacity to keep supplies and tools which are commonly used for sanding and painting. And the electric control panel contains emergency stop button, single-phase & three-phase sockets, compressed air quick release couplings, etc. This greatly increases paintwork efficiency while avoiding unnecessary entering and exiting the paint booth;
- Infrared paint curing lamp is optional;
Semi-downdraft Tri-fold access door Welded ceiling frame EPS insulated wall panel Fan unit: double inlet centrifugal fan, external motor Infrared paint curing lamp for partial paint drying job (optional)Related products
