Description
The hydraulic C frame press is a type of universal press used for sheet metal machining, suitable for sheet metal shearing, punching, blanking, bending and shallow drawing operations.

The C frame hydraulic press is designed with a hydraulic protector featuring a higher safety level. Besides, the complete press machine is also equipped with two-hand operation buttons that can realize continuous, single and micro-inching operations.

Parameters

Type			JH21-16	JH21-25B	JH21-25	JH21-45	JH21-63	JH21-80	JH21-110	JH21-125	JH21-160B	JH21-200B	JH21-250	JH21-250B	JH21-315	JH21-315B	JH21-400	JH21-400B
Type			Ⅰ	Ⅰ	Ⅰ	Ⅰ	Ⅰ	Ⅰ	Ⅰ	Ⅰ	Ⅰ	Ⅰ	Ⅰ	Ⅰ	Ⅰ	Ⅰ	Ⅰ	Ⅰ
Nominal force		kN	160	250	250	450	630	800	1100	1250	1600	2000	2500	2500	3150	3150	4000	4000
Nominal stroke		mm	2	3	3	4	4	5	6	6	6	6	8	8	8	8	10	10
Slide stroke		mm	60	60	80	100	120	140	160	160	160	200	200	250	200	250	200	250
Number of strokes	Fixed	Times/min	135	100	100	80	70	60	50	50	40	35	30	30	30	30	25	25
Number of strokes	Variable (Optional)		120-150	80-120	80-120	70-90	60-80	50-70	40-60	40-60	35-50	30-40	25-35	25-35	25-35	25-35	20-30	20-30
Max. die height		mm	220	200	250	270	300	320	350	350	350	450	430	500	430	550	430	550
Die height adjustment		mm	30	50	50	60	80	80	90	80	110	110	120	120	120	120	120	120
Distance between slide center and frame (Throat depth)		mm	160	160	210	230	300	300	350	350	380	390	420	420	420	460	420	490
Bolster area (F.B × L.R)		mm	310×700	300×680	400×700	440×810	580×900	580×1000	680×1150	680×1150	740×1300	760×1400	800×1400	800×1400	800×1400	880×1600	800×1400	940×1800
Bolster thickness		mm	65	70	80	110	110	120	140	140	150	160	170	170	170	200	180	200
Bed opening (Dia./ F.B × L.R)		mm	200×300	200×270	260×250	300×300	390×460	390×520	420×540	420×540	480×600	490×800	370×570	370×570	440×580	440×580	440×580	440×580
Slide area (F.B × L.R)		mm	250×320	270×330	300×360	340×410	400×480	420×560	500×650	540×680	580×770	600×800	650×850	650×850	650×850	700×950	690×900	720×1000
Shank hole (Dia.× Depth)		mm	φ40×60	φ40×60	φ40×60	φ40×60	φ50×80	φ50×80	φ60×80	φ60×80	φ65×90	φ65×90	φ70×90	φ70×90	φ70×90	φ70×90	φ70×90	φ70×90
Column spacing		mm	460	448	450	550	560	640	700	760	850	870	960	960	920	920	960	960
Main motor power		kW	3	3	3	5.5	5.5	7.5	11	11	15	18.5	22	22	30	30	37	37
Air cushion (Optional)	Airbag type: ejector force× stroke	kN × mm	/	/	/	23×60	40×80	40×80	60×90	60×90	80×90	100×100	100×100	100×100	100×100	100×100	100×100	100×100
Air cushion (Optional)	Cylinder type: ejector force× stroke	kN × mm	/	/	/	/	63×70	63×70	110×80	110×80	160×80	160×80	250×80	250×80	250×80	250×80	250×80	250×80
Outline dimension (F.B×L.R×H)		mm	1500×1040×2000	1350×980×2130	1300×1025×2150	1390×1125×2275	1580×1205×2580	1640×1290×2800	1850×1450×2950	1850×1490×2950	2230×1630×3180	2280×1645×3520	2800×1730×3550	2800×1730×4115	2800×1730×3710	2920×1790×4470	3140×1800×3970	3170×1880×4620
Net weight		kg	2400	2200	2600	3450	5000	6500	9300	9900	14500	16790	23700	24500	23500	29000	29900	35300

Configuration

Welded steel frame with high rigidity
Siemens motor as main motor
Dry pneumatic friction clutch, brake
Gear pair oil lubrication
Rectangular hexahedral lengthened guide; JH21-315C/400C with octahedral lengthened guide
Hydraulic overload protector
JH21-16C~45C manual die height adjustment, among which JH21-16C/25C/45C with scale indicator, JH21-25B with digital display
JH21-63C and above type adopt electric die height adjustment with digital display
JH21-45C electric die height adjustment optional, with digital display
Lifting counterbalance cylinder (excluding JH21-16C)
Dual solenoid valve
Electric forced grease lubrication system
Counterbalance cylinder: manual oil lubrication system
Equipped with a set of blowing device
Integrated control panel (including electronic cam)
International brand PLC control
International brand buttons, switches and air switches
Optional: wet clutch, air cushion (airbag type or cylinder type), automatic feed shaft, photoelectric protector, slide knockout device, as well as all kinds of automation equipment

Features of C frame press

Highly sensitive and reliable hydraulic overload protector. Once the sheet metal machine tool is overloaded, the protector will immediately relieve pressure, stop the movement of slide, and send out an electrical signal to protect the equipment and mold from damage. After overloading, it can automatically reset reducing shutdown time and improving the working efficiency of the hydraulic press.
The use of the pneumatic balance system running reduces secondary impact to improve the dynamic precision of the press.
Japanese AZBIL (TACO) dual safety solenoid valve is employed to guarantee the security and reliability of clutch operation.
Pneumatic components (filter regulator combination units, pressure regulating valve) are from SMC products.
The electrical control adopts Omron PLC for centralized control, which effectively ensures the reliability of the electrical control part.
Designed with integrated control panel including electronic cam and LED indicator light, the C frame press can realize multiple monitoring and signal indication.
