This high-speed press delivers a pressing force of 650 kN, with a stroke range of 40-60 mm and a speed of 180-350 strokes per minute. The shut height ranges from 220-280 mm, making it ideal for precision stamping of rotors, stators, terminals, lead frames, hardware parts, and can lids. It can be integrated with a feeder, decoiler, straightener, and scrap chopper to support efficient automated stamping lines.

• Constructed with high-strength cast iron and fully stress-relieved for material stability and long-term precision, ideal for continuous stamping operations.
• The dual central post structure uses special alloy copper bushings instead of traditional slide plates, minimizing dynamic friction and thermal deformation for superior accuracy.
• An optional anti-vibration counterbalance system reduces motion impact, ensuring greater precision and operational stability.
• Equipped with a die height display and hydraulic locking system, simplifying die adjustments for faster setup.
• Microcomputer-based HMI control with numerical settings and real-time fault monitoring makes operation intuitive and convenient.
• Electric die height adjustment system with indicator enhances efficiency and precision during mold setup.
