Fully Automatic Vertical Form Fill Seal Machine with Linear Weigher, SK-L420/520/620/720/820
Request a Quote
Features
- Servo motor drive and double film drawing system ensure film transporting stability and bag forming smoothness.
- International-brand air cylinder ensures the bag sealing effectiveness to prevent leaks and reduce the failure rate.
- PLC system, highly sensitive touch screen and HMI enable a high degree of automation and simple operation.
- Multilingual operating system.
- External film unwinding apparatus greatly simplifies film changeover.
Specifications
| Model | ||||||||
| Bag width range | 50-180mm | 80-200mm | 80-200mm | 100-250mm | 150-300 mm | 180-350 mm | 200-400 mm | 200-500mm |
| Bag length range | 80-240mm | 80-300mm | 80-300mm | 80-350mm | 100-400 mm | 100-500 mm | 100-600 mm | 100-700mm |
| Speed | 5-85bags/min | 5-80bags/min | 5-80bags/min | 5-70bags/min | 5-55 bags/min | 5-55 bags/min | 5-50 bags/min | 5-50 bags/min |
| Material type | PE, laminations, non-woven fabric, etc. | PE, laminations, non-woven fabric, etc. | PE, laminations, non-woven fabric, etc. | PE, laminations, non-woven fabric, etc. | PE, laminations, non-woven fabric, etc. | PE, laminations, non-woven fabric, etc. | PE, laminations, non-woven fabric, etc. | PE, laminations, non-woven fabric, etc. |
| Packaging machine dimensions | L1200 * W820 * H1350mm | L1100 * W925* H1650mm | L1450 * W1000 * H1650mm | L1430 * W1200 * H1700mm | L1780* W1300 * H1950 mm | L1800 * W1310 * H2050 mm | L1950* W1460 * H2550 mm | L2010* W1660 * H2750 mm |
| Machine weight | 350kg | 450kg | 500kg | 650kg | 700kg | 750kg | 800kg | 850kg |
If you want to know more about our VFFS machine, please feel free to contact us!
