LPG Delivery Hose Type: LG25 Manufacturer

LPG Delivery Hose Type: LG25

Request a Quote

View All: http://tech-flexcn.com/1-3-3-lpg-delivery-hose.html

The LPG delivery hose is widely used in various commercial and industrial transportation situations. The inner tube adopts rubber with conductivity lower than 106Ω/lg, which makes it resistant to oil or gasoline corrosion. It also serves as a safety function, protecting against sparks.

Advantages:

Application: Rubber hose designed for LPG (liquid petroleum gas), and petroleum products containing no more than 50% aromatic hydrocarbon;

Temperature Range: -30℃ ~ +80℃

Construction:

Tube: Black composite rubber (oil and gas resistant, conductivity R＜106Ω/lg）
Reinforcement: High strength composite fiber cord;
Cover: Composite rubber (anti-aging, ozone resistance, and safety protection from sparks flying off in all directions);

Technical Parameters:

Code No.	Size (inch)	I.D. (mm)	O.D. (mm)	W.P.		B.P.		Safety factor	MBR (mm)	Weight (Kg/m)	LengthMax (m)
Code No.	Size (inch)	I.D. (mm)	O.D. (mm)	(bar)	(psi)	(bar)	(psi)	Safety factor	MBR (mm)	Weight (Kg/m)	LengthMax (m)
LG25-6	1/4〞	6.3	13	25	360	100	1450	4	40	0.14	100
LG25-13	1/2〞	13	23	25	360	100	1450	4	78	0.35	100
LG25-19	3/4〞	19	31	25	375	100	1500	4	110	0.62	100
LG25-25	1〞	25	38	25	375	100	1500	4	150	0.82	100
LG25-32	1-1/4〞	32	45	25	375	100	1500	4	200	0.99	100
LG25-38	1-1/2〞	38	52	25	375	100	1500	4	250	1.19	100
LG25-51	2〞	51	67	25	375	100	1500	4	350	1.80	100
LG25-64	2-1/2〞	64	81	25	375	100	1500	4	420	2.28	100
LG25-76	3〞	76	94	25	375	100	1500	4	500	2.73	100
LG25-89	3-1/2〞	89	107	25	375	100	1500	4	550	3.14	61
LG25-102	4〞	102	120	25	375	100	1500	4	650	3.55	61
LG25-127	5〞	127	149	25	375	100	1500	4	800	5.20	61
LG25-152	6〞	152	174	25	375	100	1500	4	950	6.14	61
