Diesel Steam Cleaner
Request a Quote
Diesel steam cleaner uses diesel fuel as its energy source, employing combustion to generate intense heat that rapidly converts water into high-temperature, high-pressure steam. Unlike electric heating methods, diesel heating operates independently of electrical power sources, making it suitable for use in areas without electricity or with unstable power supply, offering greater mobility. Additionally, the diesel heating system boasts high thermal conversion efficiency, enabling it to reach the desired steam temperature and pressure quickly, meeting the demands of efficient cleaning.
- Pump motor power: 0.35kW
- Steam temperature: 170-210°C
- Steam pressure: 10-15bar
- Instant steam generator — produces steam in 60 seconds
- Adjustable temperature and pressure to meet various cleaning requirements
- Low-water alarm
- Overheat protection system
Applications
Vehicle body cleaning Diesel Steam Cleaning Results
Before steam cleaning
After steam cleaning
Specifications
| Model | JNX-DS |
| Power | 50kW (diesel) |
| Steam generator type | Immediate heating (diesel) |
| Burner power | 50kW (diesel) |
| Pump motor power | 0.35kW |
| Voltage/frequency | 380V 50Hz |
| Steam temperature | 170-210°C |
| Steam flow rate | 100l/h |
| Steam pressure | 10-15bar |
| Water tank capacity | 18-22L (stainless steel tank) |
| Fuel consumption | 5-6L/h (diesel) |
| Steam hose length | 10m |
| Number of steam gun | 1pc |
| Control system | PLC |
| Safety protection | Water shortage/overheat protection, low oil level sound alarm |
| Applications | construction sites, oil fields, or outdoor working environments |
| Noise level | ≤78dB |
| Emission standard | China Ⅲ Emission Standards for Non-road Vehicle |
| Dimensions | 64×57×103cm |
Configuration
Standard configuration
10 m stainless steel braided PTFE steam hose: 1 pc
Industrial steam gun:
1 pc
1 pc
Descaling agent:
1 pack
1 pack
Optional Components
High-temperature resistant steam gun
