SC9DF
Request a Quote
View All: http://sdeciepower.com
| Model | Unit | EURO III, Euro III/Euro IV/Euro V | |||||
| SC9DF240 | SC9DF260 | SC9DF280 | SC9DF300 | SC9DF320 | SC9DF340 | ||
| Type | 6 in-line cylinders, electronically controlled common rail, water cooling wet cylinder liner, front gear housing | ||||||
| Aspiration | TCI | ||||||
| Bore ×Stroke | mm | 114×144 | |||||
| Total displacement | L | 8.8 | |||||
| Rated power/rated speed | kw/r/min | 177/2200 | 192/2200 | 206/2200 | 221/2200 | 235/2200 | 251/2200 |
| Min. fuel consumption | g/kw.h | ≤192 | |||||
| Maximum torque/speed | N.m/r/min | 970/1400 | 1100/1400 | 1160/1400 | 1250/1400 | 1250/1400 | 1430/1400 |
| Noise | dB(A) | ≤97 | |||||
| Weight | kg | 840 | |||||
| Power range | ps | Power Range: 215~375PS | |||||
