Beer Fermentation Vessel, Beer Fermenter Manufacturer

Beer Fermentation Vessel, Beer Fermenter

Request a Quote

View All: http://liquidprocessplant.com/2-1-1-8-beer-fermentation-vessel-beer-fermenter.html

Stainless Steel Sanitary Tanks, Industrial Blending Mixer, High Shear Mixer

Beer fermentation vessels are used as fermentation and storage tanks for alcoholic beverages and dairy products. These beer fermenters are quite useful in a wide variety of applications in food, beverage, dairy product, pharmaceuticals, chemical engineering, pharmaceutical, and bioengineering industry.

Form

Technical Parameters

Volume (L)	Diameter (mm)	Height (mm)	Conical Bottom Head
200	600	700	60° conical bottom
300	700	700
400	800	700
500	900	700
1000	1000	1000
2000	1200	1220
3000	1300	1500
4000	1600	1800
5000	1700	2000

Features

Our beer fermentation vessels are available in a very wide range of volumes from 100L to 5000L. We can design and manufacture custom beer fermenter as your request.
The bottom is designed with conical shape, with cooling jacket. The cooling jacket is coated with an insulation layer of polyurethane foam (cold insulation).
With quick change chuck interface, the inner body is made from 304 or 316L stainless steel, with the mirror polished internal surface of Ra≤0.28μm-0.6μm. The external surface can be processed with your specific requirements such as polishing, wiredrawing, and sandblasting.
