Label Die Cutting Machine, WT-007MQJ Manufacturer

Label Die Cutting Machine, WT-007MQJ

Request a Quote

View All: http://card-equipment.com/2-1-label-die-cutting-machine-wt-007mqj.html

WT-007MQJ Label die cutter is a perfect die cutting machine to produce labels, trademarks, packaging consumables, instruction leaflets, etc.
This die cutter is capable of die-cutting multi-layer labels in one step process, thickness is up to 30mm. Regardless of what shape is required to be cut, the label die cutting machine can guarantee high cutting accuracy.

Samples

logos
Packaging consumables
Labels
Instruction leaflets

Specifications

Power supply	AC 380V/50 HZ	Sheet format	Max. 1200mmX300mm
Total power	6.0KW	Control	PLC control servo system
Cutting pressure	12T	Operators needed	1
Cutting accuracy	±0.15mm	Dimension	L2400W1200H1500MM
Weight	500KG	Product size	Max. 300X300(mm) Min. 60X60(mm)
Applicable materials	Paper card, PVC, ABS, PET, PVC/ABS composite materials, etc.	Productivity	4000cuts/H

Productivity: 4000cuts/H
Cutting accuracy:±0.15mm
Product size: Max. 300X300(mm)/Min. 60X60(mm)
Sheet format: Max. 1200mmX300mm
Control: PLC control servo system
Dimension: L2400*W1200*H1500MM
Weight: 500KG
Power supply: AC 380V/50 HZ
Total power: 6.0KW
Cutting pressure: 12T
Operators needed: 1
Applicable materials: Paper card, PVC, ABS, PET, PVC/ABS composite materials, etc.

Features

1. Sheet feeding unit
  OMRON sensor works with feeding module for high accuracy of sheet position, position parameter is adjustable;
2. Die cutting unit
  The unit adopts hydraulic system, cutting pressure and speed are adjustable; quick tool changing can be achieved when products are varying;
2. Collection unit
  After die-cutting process, finished products are automatically collected;

Die cutting molds
