The transfer system is designed to connect the slitter and welder for an automatic material collection and feeding. It effectively reduces labor costs and improves productivity and is suitable for a wide range of can sizes.
Features
- The transfer system features a human to machine interface, a PLC system, servo system, and digital control.
- The clean nylon conveyor chain effectively protects can bodies against oil pollution.
- The guide rail, bearing, electrical parts and pneumatic components are all supplied from prominent international brands.
- This transfer system has two transfer methods: linear and right-angle. Users can choose which is needed according to their factory needs.
Technical Specifications
| Models | BT-1 | BT-2 | BT-3 |
| Can inner diameter range | Φ99~Φ153mm | Φ52~Φ85mm | Φ180~Φ380mm |
| Height range | 65~265mm | 50~220mm | 100~550mm |
| Production output | 300pieces/min | 1000pieces/min | 100pieces/min |
| Electrical mains | AC380V, 50Hz, 2.5KW | AC380V, 50Hz, 5KW | |
| Air pressure & consumption | 0.5MPa, 20L/min | ||
