5000-8000W Traction Motor, PMDC Brushless Motor TZ210BX-P
Request a Quote
Website: http://motors-manufacturer.com/2-25-5000-8000w-traction-motor-pmdc-brushless-motor-tz210bx-p.html
Your Motion
Application: electric forklift, electric vehicle, elevators, etc.
Technical Specifications
| Rated Power (W) | 5000 | 7000 | 8000 |
| Max Power (W) | 10000 | 14000 | 16000 |
| Rated Voltage(V) | 56--90 | 56--90 | 56--90 |
| Rated Revolution (RPM) | 1600 | 1800 | 2200 |
| Max Revolution (RPM) | 2600 | 2600 | 3200 |
| Rated Torque (N•m) | 29.84 | 37.1 | 34.7 |
| Max Torque (N•m) | 60.0 | 74.0 | 85.0 |
| Rated Efficiency (%) | 90 | 90 | 90 |
| Working Cycle (min.) | S2-15 | S2-15 | S2-15 |
| Insulation Class | H | H | H |
| Protection Level | IP54 | IP54 | IP54 |
| Length (L/mm) | 299 | 299 | 299 |
Note: UNITE MOTOR can customize BLDC traction motors according to your application requirements and working conditions.
