Flexo Printing Machine, ZBS-450 (1-6 Colors)
Request a Quote
- Printing speed 50m/min
- Printing color 1-6 colors
- Max. width of paper 480mm
- Max .printing width 450mm
Features
- This ZBS-450 flexo printing machine chooses the ceramic anilox roll for ink transfer. It is able to print with 1 to 3 colors respectively.
- There are brakes, clutches and automatic tension controller mounted for controlling the unwinding and rewinding devices.
- Aside from the printing plate that can be adjusted within 360 degree, each printing unit also adopts the hot air IR dryer.
- Installed with one die cutting station, the flexo printing machine is able to finish material feeding, printing, vanishing, drying, laminating, die cutting and rewinding at one stroke.
- When it stops, its ink rollers will be parted from the printing roller and keep running.
- Our flexo printing machine is configured with the imported timing motor that features continuously variable frequency. It is very suitable for printing the trade invoice, medicine package, superior adhesive label, etc.
Technical Specifications
| Model | ZBS-450B | ZBS-450 | ZBS-450 | ZBS-450 | ZBS-450 | ZBS-450 |
| Printing speed | 50m/min. | 50m/min. | 50m/min. | 50m/min. | 50m/min. | 50m/min. |
| Printing color | 1 color | 2 colors | 3 colors | 4 colors | 5 colors | 6 colors |
| Max. width of paper | 480mm | 480mm | 480mm | 480mm | 480mm | 480mm |
| Max .printing width | 450mm | 450mm | 450mm | 450mm | 450mm | 450mm |
| Max. unwinding/rewinding diameter | 600mm | 600mm | 600mm | 600mm | 600mm | 600mm |
| Printing length | 175-355mm | 175-355mm | 175-355mm | 175-355mm | 175-355mm | 175-355mm |
| Thickness of flexo plate | 1.7mm or 1.14mm | 1.7mm or 1.14mm | 1.7mm or 1.14mm | 1.7mm or 1.14mm | 1.7mm or 1.14mm | 1.7mm or 1.14mm |
| Precision of chromatography | ±0.1mm | ±0.1mm | ±0.1mm | ±0.1mm | ±0.1mm | ±0.1mm |
| Dimensions | 2m×1.35m×2m | 2.1m×1.35m×2.1m | 2.1m×1.35m×2.1m | 2.1m×1.35m×2.3m | 2.1m×1.35m×2.6m | 2.1m×1.35m×3.1 m |
| Machine weight | About 1450kg | About 1950kg | About 2050kg | About 2200kg | About 2400kg | About 2600kg |
Shipping Information
| Packing | Export standard wooden case |
| Model No. | ZBS-450 |
| Standard | 1-6 colors |
| Productivity | 15sets per month |
| Unit Price/Payment | USD16000-USD65000 |
| H.S. Code | 84431600 |
| Trademark | WEIGANG |
| Origin | China |
| Min. Order | 1 set |
| Transportation | Land, sea, air |
Options
- Web guiding system
- UV dryer
- Corona treater
Details
- Single color with 1UV
- Single color with 1UV
- Single color with 1UV and 3 hot air driers
- Die cutting station
