Independent servo-driven feeding with vacuum front-edge suction using dual air chambers. Variable-frequency airflow adjustment provides stable and precise sheet feeding. Equipped with a servo feeding system, stable feeding system, and one-touch machine reset system for fast and convenient job changeover.
Left and right side guides, along with the rear paper stop, are computer-controlled and move smoothly through a precision guiding mechanism. A built-in side-tapping function helps keep sheets properly aligned.

The printer features full-process vacuum-assisted sheet transport with inverter-controlled adjustable suction. A doctor blade system paired with a ceramic anilox roll ensures high-line, precise printing with consistent doctoring pressure. A pneumatic diaphragm pump provides stable ink circulation and fast cleaning. Print cylinders include horizontal and circumferential reference marks for easy registration and plate mounting, while the design supports quick replacement of doctor blades and anilox components. Plate-cleaning memory and automatic reset functions further streamline operation.

The infrared drying system eliminates problems caused by insufficiently dried water-based inks, enhancing both print quality and coating performance. A pneumatically controlled lift mechanism allows the dryer chamber to rise quickly and adjust the drying width to match the board size, improving energy efficiency. Full vacuum-assisted sheet transport with variable suction ensures stable feeding, while adjustable air gates accommodate different board lengths. An optional UV curing system is also available.
