Labelling Machine
Request a Quote
The labelling machine is suitable for automatic labelling of blood collection tubes. It uses a touch screen control for a simple operation, stable performance, a high running efficiency and excellent applicability.
Technical Specs
| Applicable tube size | Diameter 8mm (height 120mm); Diameter 13mm ( height 75mm or 100mm) Diameter 16mm |
| Capacity | 20000-35000 pcs/h |
| Labelling accuracy | ±1mm |
| Power supply | AC220V |
| Power | 450W |
| Weight | 200kg |
| Overall size (L*W*H) | 2000*500*1700mm |
Main Features
- With an advanced PLC control system, the labelling machine runs both stable and quickly.
- The machine body is made of 304 stainless steel and a high-grade aluminum alloy.
- No labelling no tube. Automatic alarm for label missing and breaking.
- No need to add or replace parts and only simple adjustment is required to label tubes of 8mm, 13mm and 16mm with one machine.
