5 Ply Automatic Flute Laminator
Request a Quote
Sheet to sheet cardboard laminator for making multi-layer corrugated board
Our 5 Ply automatic flute laminator is an innovative corrugated cardboard laminating solution widely used in the packaging industry, designed to create multi-layer corrugated boards efficiently. Ideal for manufacturers targeting high-quality, multi-layer corrugated board production, this flute laminator effortlessly manages both single-layer lamination and complex configurations, including 1 2 and 3 2 layer setups. Designed to meet the challenges of a dynamic packaging industry, our flute laminator enhances operational efficiency and precision, accommodating a diverse range of corrugated board applications.
Specifications
| Model | ||
| Max. paper size (L×W) (mm) | 1450×1100 | 1450×1400 |
| Min. paper size (L×W) (mm) | 450×450 | 450×450 |
| Max. weight of top paper (g/m²) | 800 | 800 |
| Min. weight of top paper (g/m²) | 180 | 180 |
| Max. weight of bottom paper (g/m²) | 800 | 800 |
| Min. weight of bottom paper (g/m²) | 300 | 300 |
| Max. thickness of bottom paper (mm) | 8 | 8 |
| Max. thickness of laminated paper (top paper bottom paper) (mm) | 10 | 10 |
| Max. speed (sheets/h) | 6000 | 6000 |
| Total power (kW) | 19.7 | 21.2 |
| Machine dimensions (mm) | 18560×2100×2600 | 19970×2250×2600 |
Features
- Supports a broad range of paper sizes, ideal for large-scale production, enhancing productivity
- Processes up to 6000 sheets per hour, meeting the needs of fast-paced production schedules
- Features advanced suction belts and precise side guides for flawless paper positioning before lamination
- Equipped with two robust gluing systems for consistent adhesive application, crucial for high-quality output
- Ensures a firm and uniform bond between sheets with an innovative pressing system, resulting in exceptional lamination quality
