Open Frame Gasoline Inverter Generators
Request a Quote
5kW/10kW/20kW Gasoline Genset
5kW/10kW/20kW Gasoline Genset
Features
- Advanced inverter for stable performance
Provides stable, clean power with total harmonic distortion (THD < 3%) to protect sensitive electronics like computers, instruments, and communication equipment. - Compact open-frame design for easy mobility
The open-frame structure provides a smaller overall size, reducing weight, and a more compact footprint, facilitating ease of movement and transportation for outdoor tasks, emergency scenarios, or temporary power supply. - Smart fuel-saving system
The open frame inverter generator is equipped with intelligent variable-speed control, the generator automatically adjusts engine speed based on load, reducing fuel consumption and emissions under light-load conditions. - Quick-start function
Features electric start (with recoil start backup on select models), enabling fast and reliable power restoration in case of outages. - Rugged and easy maintenance
Built with a high-quality engine and efficient inverter alternator that offer excellent cooling performance and overload resistance. The open layout makes routine maintenance quick and convenient. - Parallel connection power expansion
Supports parallel operation, allowing multiple compatible units to be connected for increased output and handling higher power demands.
Specifications
| Genset Model | | | | |
| Alternator | Excitation Mode | PMG inverter type | ||
| Rated Power (kW) | 10 | 20 | 5 | |
| Max. Power (kW) | 11 | 21 | 5.5 | |
| Rated Voltage (V) | 220 & 380 (double voltage) | 220 & 380 (double voltage) | 220 | |
| Rated Frequency (Hz) | 50 | 50 | 50 | |
| Phase | Single & three phase (double voltage) | Single & three phase (double voltage) | Single phase | |
| Power Factor (COSφ) | 1.0 & 0.8 | 1.0 & 0.8 | 1.0 | |
| Insulation Class | F | F | F | |
| Engine | Engine Model | DH550 | DH999 | DH275 |
| Bore Size×Stroke (mm) | 94×76 | 90×78.5 | 75×62 | |
| Displacement (cc) | 550 | 999 | 275 | |
| Engine Type | 1 cylinder, air-cooled, OHV (overhead valve) | 2 cylinder, air-cooled, OHV (overhead valve) | 1 cylinder, air-cooled, OHV (overhead valve) | |
| Fuel Type | Gasoline | Gasoline | Gasoline | |
| Oil Capacity (L) | 1.2 | 2.4 | 0.7 | |
| Starting System | Recoil/Electric Start | Electric Start | Recoil/Electric Start | |
| Genset | Fuel Tank (L) | 35 | 35 | 20 |
| Noise Level (dBA/7m) | 78 | 85 | 75 | |
| Dimension (mm) | 703×611×686 | 815×625×937 | 600×430×620 | |
| Weight (kg) | 85 | 155 | 50 | |
