10kW-20kW Gasoline Genset
10kW-20kW Gasoline Genset
Automatic Transfer Switch (ATS)
The generator is compatible with a fully automatic ATS control panel, which features status indicators for utility power, generator operation, automatic mode, and fault alarms.
When the ATS detects a utility power outage, the generator will start automatically, and the ATS will transition the power supply to the generator. Once utility power is restored, the system will implement a delay shutdown period of 30 to 60 minutes, after which the ATS will automatically switch back to grid power.
The ATS configuration guarantees an uninterrupted power supply with seamless transitions, supported by a vertical single-cylinder, 4-stroke, forced air-cooled engine recognized for low emissions and stable performance.
Features
- The gasoline generator is powered by a V-type twin-cylinder, 4-stroke, forced air-cooled engine for stable output and low emissions. Built to handle medium to heavy-duty loads in a variety of environments.
- The genset is equipped with a full copper alternator and an automatic voltage regulator (AVR), ensuring steady voltage output, reliable excitation, and protection for sensitive equipment.
- Reinforced with a heavy-duty steel frame, the gasoline genset comes standard with caster wheels, allowing smooth transport and deployment in varied environments.
- The silent gasoline genset is equipped with complete safety measures, including overload protection and low oil shutdown to extend service life and safeguard the generator during high-load use.
- Equipped with a specially optimized silencing system to effectively minimize noise levels—perfect for settings that demand quieter power solutions.
Product Details
Specifications
| Genset Model | | | | | |
| Alternator | Excitation Mode | Brushed, self-excitation, AVR (automatic voltage regulation) | |||
| Prime Power (kW) | 10 | 12 | 15 | 18 | |
| Standby Power (kW) | 10.5 | 13 | 16 | 20 | |
| Rated Voltage (V) | 220/380 | 220/380 | 220/380 | 220/380 | |
| Rated Frequency (Hz) | 50 | 50 | 50 | 50 | |
| Phase | Single phase Three phase | ||||
| Power Factor (COSφ) | 1/0.8 | 1/0.8 | 1/0.8 | 1/0.8 | |
| Insulation Class | F | F | F | F | |
| Engine | Engine Model | DH740 | DH760 | DH999 | DH999 |
| Bore Size×Stroke (mm) | 78×70 | 82×76 | 90×78.5 | 90×78.5 | |
| Displacement (cc) | 740 | 760 | 999 | 999 | |
| Engine Type | 2 cylinder, air-cooled, OHV (overhead valve) | ||||
| Fuel Type | Gasoline | ||||
| Oil Capacity (L) | 1.6 | 1.6 | 2.4 | 2.4 | |
| Starting System | Electric Start | ||||
| Genset | Fuel Tank (L) | 30 | 30 | 30 | 30 |
| Noise Level (dBA/7m) | 75 | 75 | 75 | 75 | |
| Dimension (mm) | 1150×750×870 | 1150×750×870 | 1300×800×930 | 1300×800×930 | |
| Weight (kg) | 245 | 260 | 310 | 320 | |
