Water-Cooled Silent Gasoline Generators (Four Cylinder)
Request a Quote
15kW-40kW Gasoline Genset
15kW-40kW Gasoline Genset
Specifications
| Genset Model | | | | | | |
| Alternator | Excitation Mode | Brushed, self-excitation, AVR (automatic voltage regulation) | Brushed, self-excitation, AVR (automatic voltage regulation) | Brushed, self-excitation, AVR (automatic voltage regulation) | Brushless PMG type | Brushless PMG type |
| Prime Power (kW) | 15 | 20 | 25 | 30 | 40 | |
| Standby Power (kW) | 16 | 21 | 26 | 31 | 45 | |
| Rated Voltage (V) | 220/380 | 220/380 | 220/380 | 380 | 380 | |
| Rated Frequency (Hz) | 50 | 50 | 50 | 50 | 50 | |
| Phase | Single phase Three phase | Single phase Three phase | Single phase Three phase | Three phase | Three phase | |
| Power Factor (COSφ) | 1/0.8 | 1/0.8 | 1/0.8 | 0.8 | 0.8 | |
| Insulation Class | F | F | F | F | F | |
| Engine | Engine Model | 465Q | 465Q | CG12 | CG12 | RQ23 |
| Bore Size×Stroke (mm) | 65×78 | 65×78 | 65×78 | 65×78 | 91×86 | |
| Displacement (cc) | 998 | 998 | 1498 | 1498 | 2230 | |
| Engine Type | 4 cylinder, water-cooled | |||||
| Fuel Type | Gasoline | |||||
| Oil Capacity (L) | 2.8 | 2.8 | 3 | 3 | 4.2 | |
| Starting System | Electric Start | |||||
| Genset | Fuel Tank (L) | 30 | 30 | 35 | 35 | 50 |
| Noise Level (dBA/7m) | 75 | 75 | 75 | 75 | 75 | |
| Dimension (mm) | 1160×725×850 | 1160×725×850 | 1300×725×850 | 1300×725×850 | 1630×1001×952 | |
| Weight (kg) | 282 | 290 | 324 | 324 | 560 | |
