MEMS SM 1xN Optical Switch - Cylindrical

Request a Quote

Website: http://laserdiodedevice.com/7-1-1-mems-sm-1xn-switch-cylindrical.html

Optical Specifications

Parameter		Value	Unit	Note
Wavelength Range		13:1290~1330 15:1525~1568 16:1600-1650	nm	Single-band: 13, 15, or 16 Dual-band: 13&15 or 15&16 Full-band: 1290~1650
Test Wavelength		1310/1550/1625	nm	Each test wavelength is the CWL of a specific wavelength range
Channels		2~128		N
Insertion Loss	1x2	≤0.6	dB	1. IL is measured at CWL, 23°C 2. IL is for single-band. Dual-band adds 0.2dB 3. If with connectors, IL increases by 0.2~0.3dB
	1x4	≤0.8
	1x8
	1x12	≤1.0
	1x16
	1x24	≤1.2
	1x32
	1x48	≤1.3
	1x64
Return Loss		≥45	dB	Or customer-defined
Repeatability		≤0.05	dB	Repeatability is defined after 100 cycles
Crosstalk	N=2	≥50	dB	Or customer-defined
	2
Polarization Dependent Loss		≤0.2	dB
Wavelength Dependent Loss	2≤N≤32	≤0.3	dB	WDL is measured at CWL ±20nm, 23°C
	32
Temperature Dependent Loss	N≤32	≤0.3	dB
	32
Switch Time	N≤16	≤5	ms	1. Excluding protocol transmission time 2. When using optimized voltage ramp 3. Faster 1xN switching time version available upon request
	16
Durability		≥1x10⁹	cycle
Maximum Optical Power		≤500	mW

Electrical and Mechanical Specifications

PARAMETER	VALUE	UNIT	NOTE
Latching Type	Non-latching
Control Type	Direct voltage
Supply Voltage	<15	V	1x2
	<60		2<N≤64
Power Consumption	Close to 0	W
Dimension	Ø5.5×26	mm	N=2
	Ø5.5×43		2<N≤16
	Ø6.3×43		2<N≤16
	Ø6.3×47		16<N≤32
	Ø6.3×52		32<N≤64

（All specifications apply to cylindrical package.）
