MEMS PM 1xN Optical Switch – Cylindrical
Request a Quote
Optical Specifications
| PARAMETER | VALUE | UNIT | NOTE | |
| Wavelength Range | 13:1290~1330 15:1525~1568 | nm | Single-band: 13 or 15 | |
| Test Wavelength | 1310 or 1550 | nm | Each test wavelength is the CWL of a specific wavelength range | |
| Channels | 2~8 | N | ||
| Insertion Loss | 1x2 | ≤1.0 | dB | IL is measured at CWL, 23° C If with connectors, IL increases by 0.2~0.3dB |
| 1x4 | ≤1.2 | |||
| 1x8 | ≤1.4 | |||
| Return Loss | ≥45 | dB | Or customer-defined | |
| Repeatability | ≤0.05 | dB | Repeatability is defined after 100 cycles | |
| Crosstalk | ≥45 | dB | Or customer-defined | |
| Polarization Dependent Loss | ≤0.2 | dB | ||
| Wavelength Dependent Loss | ≤0.3 | dB | WDL is measured at CWL ±20nm, 23° C | |
| Temperature Dependent Loss | ≤0.3 | dB | ||
| Extinction Ratio | ≥18 | dB | ||
| Switch Time | ≤5 | ms | 1.Excluding protocol transmission time 2.When using optimized voltage ramp 3.Faster 1xN switching time version available upon request | |
| Durability | ≥1x10⁹ | cycle | ||
| Maximum Optical Power | ≤500 | mW | ||
（All specifications apply to cylindrical package.）
Electrical and Mechanical Specifications
| PARAMETER | VALUE | UNIT | NOTE |
| Latching Type | Non-latching | ||
| Control Type | Direct voltage | ||
| Supply Voltage | <60 | V | |
| Power Consumption | Close to 0 | W | |
| Dimension | Ø6.3×43 | mm |
（All specifications apply to MS M1）
Environmental Conditions
| PARAMETER | VALUE | UNIT | NOTE |
| Operation Temperature | -5~65 | °C | |
| Storage Temperature | -40~85 | °C | |
| Operation Humidity | 5~95 | %RH | |
| Storage Humidity | 5~95 | %RH |
