Material Handling Fans, Transport Fans
Request a Quote
As an industrial fan, the material handling fan is used for conveying wood shavings, saw dust, granules, wood chips, fibers, etc. This transport fan has found wide applications in the wood production mills, furniture factories, wood processing factories and so on.
Technical Parameters
| Model | Air Flow (m³/h) | Overall Pressure (Pa) | Power (kW） |
MQS-54NO-5# | 2997-12280 | 2100-3500 | 5.5-18.5 |
MQS-54NO-6# | 4060-23700 | 2470-4900 | 11-37 |
MQS-54NO-8# | 6400-42400 | 1780-5050 | 11-75 |
MQS-54NO-10# | 3600-54900 | 1970-4850 | 18.5-75 |
Features of Transport Fans
- A large flow of air ensures smooth transportation of materials with bigger size.
- Designed as vertical fans, transport fans suit for both indoor and outdoor installations.
- The material handling fans can be tailor made to suit for a wide range of materials and conditions.
- It features robust construction, high reliability, low noise, high efficiency, and low maintenance cost.
