Excavator-Mounted Air Compressor
- Output Pressure: 5-8 bar
- Free Air Delivery (FAD): 10 m³/min
The excavator-mounted air compressor is primarily composed of a hydraulic motor that drives a screw air compressor through a transmission system, a control system, and auxiliary components. The oil, water, and air circuits utilize independent cooling systems equipped with large-diameter fans, allowing the compressor to adapt to extreme working conditions such as severe cold or intense heat while ensuring stable operation.
| Free Air Delivery (FAD) | 10m³/min |
| Output Pressure | 5-8 bar |
| Screw Air Compressor | Primary Compression |
Oil filter assembly
Air filter assembly
Screw airend
Radiator
Oil-air separator tank
Piston motor
The working principle of the equipment involves a hydraulic motor driving a screw compressor to compress air into high-pressure gas. It is mainly used in hydraulic rock drilling equipment or other pneumatic devices to provide pneumatic power for tasks such as debris blowing, dust suppression, cleaning, and lubrication. As a mining-grade compressor, the K710Y can be mounted on excavators ranging from 48T to 65T.
