PYB/PYZ/PYD Series Cone Crusher
Request a Quote
This series of cone crushers is widely used in metallurgy, construction, hydropower, transportation, chemical, and building materials industries. It is suitable for crushing various ores and rocks with high hardness and above medium hardness.
Applicable Materials
- Metal Ores
- Non-Metal Ores
Dimensions
| Model | Length L1 (mm) | Width W1 (mm) | Height H1 (mm) |
| | 2692 | 1640 | 2350 |
| | 2692 | 1640 | 2350 |
| | 2692 | 1640 | 2350 |
| | 2790 | 1878 | 2844 |
| | 2790 | 1878 | 2844 |
| | 2790 | 1878 | 2844 |
| | 3910 | 2894 | 3809 |
| | 3910 | 2894 | 3809 |
| | 3910 | 2894 | 3809 |
| | 6640 | 2900 | 5057 |
| | 6640 | 2900 | 5057 |
| | 6640 | 2900 | 5057 |
Technical Parameters
| Model | Max. feeding size (mm) | Discharging size (mm) | Moving cone diameter (mm) | Shaft speed (r/min) | Capacity (t/h) | Power (kW) |
| | 115 | 30-50 | 900 | 333 | 50-90 | 55 |
| | 60 | 15-30 | 900 | 333 | 20-65 | 55 |
| | 50 | 5-15 | 900 | 333 | 15-50 | 55 |
| | 145 | 30-50 | 1200 | 300 | 110-168 | 110 |
| | 100 | 20-50 | 1200 | 300 | 60-135 | 110 |
| | 50 | 10-20 | 1200 | 300 | 42-105 | 110 |
| | 215 | 60-100 | 1750 | 245 | 400-600 | 180 |
| | 185 | 30-50 | 1750 | 245 | 200-350 | 180 |
| | 85 | 15-30 | 1750 | 245 | 120-200 | 180 |
| | 300 | 100-200 | 2200 | 220 | 650-1000 | 330 |
| | 230 | 70-150 | 2200 | 220 | 480-800 | 330 |
| | 100 | 35-60 | 2200 | 220 | 320-450 | 330 |
Projects
Aggregate Plant Project in HubeiGranite Crushing Project in Ghana
What turnkey solution is common for producing aggregates for asphalt mixing plants?
The focus is on stable particle size ranges and control of flaky particles. A typical configuration is a jaw crusher combined with a cone crusher or impact crusher, followed by closed-circuit screening.
For copper ore projects, what crusher configuration is commonly used?
The commonly searched configuration is a classic process consisting of jaw crushing for primary crushing, cone crushing for medium and fine crushing, and closed-circuit screening.
