DXDK900, Dual-Servo 4-Side Seal Sachet Packaging Machine for Granule & Liquid
Pharmaceutical Packaging Machinery Since 1998
- Max. packaging speed: 400 packs/min
- Suitable for granules and pellets using composite films with four-side sealing
The sachet packaging machine adopts a PLC automatic control system with a servo-driven longitudinal sealing unit. It features automatic double-side registration for printed film and real-time tracking adjustment, while the main drive is equipped with stepless variable-frequency speed control.
The equipment can continuously and automatically complete sachet forming, dosing, filling, sealing, slitting, batch coding, and counting. Tear notches as well as longitudinal and transverse easy-tear lines can be formed during operation. Once filling is completed, multiple sachets can be packaged simultaneously, and edge trim is automatically collected. The equipment is suitable for automatic filling and packaging of granules, powders, and similar materials.
- Four-side sealing design with simultaneous multi-lane sachet packaging
- Photoelectric mark tracking ensures automatic front-and-back print registration with accurate positioning
- Filling, longitudinal and transverse sealing, batch coding, tear lines, and cutting are adjusted via the HMI
- Stepless sachet length adjustment without changing forming molds
- Modern appearance with a large-size color touchscreen and bilingual (Chinese/English) user interface for intuitive operation
| Film thickness | 0.05–0.1 mm |
| Cutting frequency | 20–60 cuts/min (adjustable) |
| Packing dose | Granules: 2–20 g/sachet Liquid / semi-liquid: 5–40 ml/sachet |
| Bag length | 50–120 mm |
| Bag width | 65–120 mm |
| Max. film width | 900 mm |
| Max. packaging speed | 400 packs/min |
| Max. number of longitudinal lanes | 10 sachets |
| Air consumption | 3.2 L/h |
| Installed power | 8.75 kW |
| Power supply | 380 V, 50 Hz |
| Dimensions (L*W*H) | 1500 × 1540 × 2200 mm |
| Weight | 1200 kg |
-
- Feeding station
-
- Sealing station
The customer’s existing packaging line could no longer meet production requirements due to high failure rates of outdated equipment. Based on Tonghua Xinhua Pharmaceutical’s industry characteristics and specific needs, Huaxin Package supplied the DXDK900 full-servo sachet packaging machine, achieving stable filling of powder and granule products and effectively controlling dosage variation.
Full-servo machines provide higher precision and speed and are suitable for high-standard production environments, while dual-servo models are more cost-effective and better suited for medium-output applications.
Servo drives combined with PLC control and stepless variable-frequency speed regulation enable stable high-speed multi-lane packaging and automatic edge-trim collection, accommodating a wide range of sachet sizes.
Sachet packaging machines use servo motor drives and PLC control with stepless variable-frequency speed regulation. They support simultaneous multi-lane packaging and automatic edge-trim collection, adapting to different packaging sizes and formats.
