Integrated Roll-Film Bagging & Filling Machine, YL-140/190
Request a Quote
Horizontal Form Fill & Seal
- Independent Mechanical Grippers
- Rapid format changeovers via touch screen
- Packaging speed up to 100 pouches per min
- Applicable to flat bag, stand-up bag, zipper bag and various bags
- Suitable for sauces, granules, and other various materials
Specifications
| Model | ||
| Capacity | 50 - 90 pouches/min | 50 - 70 pouches/min |
| Pouch size | Length: 100 - 240mm; Width: 80 - 140mm | Length: 100 - 300mm; Width: 100 - 190mm |
| Packing weight | Max. weight 1kg | Max. weight 1kg |
| Sealing method | Heat seal | Heat seal |
| Power consumption | 13.5kW | 14kW |
| Power supply | 3-phase AC380V，50/60Hz | 3-phase AC380V，50/60Hz |
| Compressed air | 0.6 - 0.7mpa，1.5m³/min | 0.6 - 0.7mpa，1.5m³/min |
| Machine weight | 5800kg | 6300kg |
| Pouch style | Flat pouch, stand-up pouch, zipper pouch | Flat pouch, stand-up pouch, zipper pouch |
| Machine dimensions | Length: 6100mm; Width: 2000mm; Height: 1530mm | Length: 6600mm; Width: 2500mm; Height: 1580mm |
Working Process
- Film Unwinding
- Bag Making
- Vision Inspection
- Pouch Forming
- Automatic Packaging
- Finished Product Output
