ZW Series Vibrating Feeder

Request a Quote

Website: http://stonecrusher-en.com/zw-vibrating-feeder-4-4.html

This vibrating feeder features a simple and well-designed structure with strong and reliable construction. It adopts thin oil lubrication, offers easy vibration amplitude adjustment, and requires minimal maintenance. With convenient servicing and variable-frequency speed control, it ensures continuous and uniform feeding.

Applicable Materials

• Metal Ores
• Non-Metal Ores

Iron OreManganese OreChrome OreCopper OreLead-Zinc OreBauxiteNickel OreTin OreGold OreTungsten OreMolybdenum OreSilver Ore

LimestoneDolomiteMarbleDiabaseGraniteBasaltSandstone
(Quartz Sandstone)River PebbleTuffBariteFluoriteGypsumConstruction & Demolition WasteTailings

Dimensions

Model	Length L1 (mm)	Width W1 (mm)	Height H1 (mm)
ZW0820	1945	1420	1515
ZW0940	3885	1525	2015
ZW1020	1945	1620	1515
ZW1220	1945	1820	1515
ZW1420	1945	2020	1515
ZW1620	2102	2246	1508
ZW1150	4855	1765	2320
ZW1250	4855	1865	2320
ZW1260	5730	1945	2825
ZW1360	5730	2045	2825
ZW1560	5730	2245	2825
ZW1760	5730	2445	2825
ZW1820	1945	2446	1498
ZW1838	3825	2705	2390
ZW1845	4420	2750	2580
ZW1860	5730	2545	2825
ZW2060	5730	2745	2825
ZW2245	4420	3150	2580

Technical Parameters

Model	Feeder trough size (mm)	Max. feeding size (mm)	Spindle speed (r/min)	Double amplitude (mm)	Installation inclination (°)	Capacity (t/h)	Power (kW)
ZW0820	800×2000	≤200	500-850	8-10	14	80-200	11
ZW0940	900×4000	≤500	500-850	8-10	14	80-200	15
ZW1020	1000×2000	≤250	500-850	8-10	14	300-400	11
ZW1220	1200×2000	≤250	500-850	8-10	14	350-600	15
ZW1420	1400×2000	≤250	500-850	8-10	14	400-700	15
ZW1620	1600×2000	≤250	500-850	8-10	14	450-800	18.5
ZW1150	1100×5000	≤600	500-850	8-10	14	360-550	22
ZW1250	1200×5000	≤700	500-850	8-10	14	400-600	30
ZW1260	1200×6000	≤700	500-850	8-10	18	400-600	37
ZW1360	1300×6000	≤700	500-850	8-10	18	450-800	37
ZW1560	1500×6000	≤900	500-850	8-10	18	450-1100	45
ZW1760	1700×6000	≤1000	500-850	8-10	18	500-1200	45
ZW1820	1800×2000	≤250	500-850	8-10	14	400-850	22
ZW1838	1800×3800	≤1000	500-850	8-10	20	650-2200	37
ZW1845	1800×4500	≤1000	500-850	8-10	20	650-2200	45
ZW1860	1800×6000	≤1000	500-850	8-10	18	550-1300	45
ZW2060	2000×6000	≤1000	500-850	8-10	18	650-1400	55
ZW2245	2200×4500	≤1000	500-850	8-10	20	800-2500	45

Projects

Aggregate Project in Qingyuan, GuangdongAggregate Plant Project in Hengyang, Hunan (7.5 million tons per year)Aggregate Project of Wuzhou City Investment (Huaqun) in GuangxiLimestone Aggregate Production Line Project of Tianjing Calcium Company in Jingzhou, Hubei (5 million tons per year)Aggregate Plant Project of Lida Company in Fangchenggang, Guangxi

What is a typical use case for a vibrating grizzly feeder in mining?

It is used for coarse pre-screening and uniform feeding, removing fine materials in advance to reduce the load on the primary crusher.

How is a turnkey quarry solution adapted for multi-spec product output?

By using multi-deck screening and adjustable closed-circuit ratios, different particle size products can be produced simultaneously.
