YKJ Series Vibrating Screen
Request a Quote
This series of vibrating screens features a circular motion trajectory and is specifically designed for aggregate production lines. It can also be used for product classification in coal preparation, mineral processing, building materials, power generation, and chemical industries.
Applicable Materials
- Metal Ores
- Non-Metal Ores
Dimensions
| Model | Length L1 (mm) | Width W1 (mm) | Height H1 (mm) |
| | 6780 | 2520 | 1450 |
| | 6780 | 2520 | 1850 |
| | 6780 | 2720 | 1450 |
| | 6780 | 2720 | 1450 |
| | 7045 | 2950 | 1775 |
| | 6780 | 2920 | 1450 |
| | 6780 | 2920 | 1950 |
| | 6780 | 2730 | 1670 |
| | 8065 | 2730 | 1940 |
| | 7970 | 2930 | 1670 |
| | 8065 | 2930 | 1940 |
| | 7970 | 3230 | 1670 |
| | 8065 | 3230 | 1940 |
| | 7560 | 3565 | 1845 |
| | 7560 | 3565 | 2250 |
| | 8030 | 3900 | 1666 |
| | 8230 | 3900 | 2170 |
| | 8700 | 3970 | 2080 |
| | 8545 | 4830 | 1940 |
| | 8725 | 4830 | 2430 |
| | 9045 | 4830 | 1940 |
| | 9225 | 4830 | 2430 |
| | 11450 | 5350 | 2550 |
Technical Parameters
| Model | Screen layers | Screen size (mm) | Max. feeding size (mm) | Spindle speed (r/min) | Double amplitude (mm) | Installation inclination (°) | Capacity (t/h) | Power (kW) | Installation dimensions (mm) |
| 2 | 1800×6000 | 250 | 820 | 8-10 | 20 | 50-300 | 18.5 | 6060×2520×3550 | |
| 3 | 1800×6000 | 250 | 820 | 8-10 | 20 | 50-300 | 22 | 6060×2520×3980 | |
| 2 | 2000×6000 | 250 | 820 | 8-10 | 20 | 100-400 | 18.5 | 6060×2720×3550 | |
| 3 | 2000×6000 | 250 | 820 | 8-10 | 20 | 100-400 | 22 | 6060×2720×3980 | |
| 2 | 2200×6000 | 400 | 820 | 8-10 | 24 | 400-800 | 30 | 5890×2930×4450 | |
| 2 | 2400×6000 | 300 | 820 | 8-10 | 20 | 150-600 | 22 | 6060×3120×3650 | |
| 3 | 2400×6000 | 300 | 820 | 8-10 | 20 | 150-600 | 30 | 6060×3120×4080 | |
| 2 | 2000×7000 | 300 | 820 | 8-10 | 23 | 200-480 | 22 | 6880×2760×4390 | |
| 3 | 2000×7000 | 300 | 820 | 8-10 | 23 | 200-480 | 30 | 6880×2760×4820 | |
| 2 | 2200×7000 | 300 | 820 | 8-10 | 23 | 200-550 | 22 | 6880×2960×4390 | |
| 3 | 2200×7000 | 300 | 820 | 8-10 | 23 | 200-550 | 30 | 6880×2960×4820 | |
| 2 | 2500×7000 | 300 | 820 | 8-10 | 23 | 250-650 | 30 | 6880×3260×4390 | |
| 3 | 2500×7000 | 300 | 820 | 8-10 | 23 | 250-650 | 37 | 6880×3260×4820 | |
| 2 | 2600×6500 | 300 | 820 | 8-10 | 23 | 280-680 | 30 | 6416×4288×3556 | |
| 3 | 2600×6500 | 300 | 820 | 8-10 | 23 | 280-680 | 37 | 6414×4288×4133 | |
| 2 | 3000×7000 | 300 | 820 | 8-10 | 23 | 300-800 | 22×2 | 6880×3760×4390 | |
| 3 | 3000×7000 | 300 | 820 | 8-10 | 23 | 300-800 | 30×2 | 6880×3760×4820 | |
| 3 | 3000×7500 | 300 | 820 | 8-10 | 23 | 300-800 | 30×2 | 7345×4830×5200 | |
| 2 | 3600×7500 | 300 | 820 | 8-10 | 20 | 700-1000 | 37×2 | 7500×4830×4620 | |
| 3 | 3600×7500 | 300 | 820 | 8-10 | 20 | 700-1000 | 45×2 | 7510×4830×5110 | |
| 2 | 3600×8000 | 300 | 820 | 8-10 | 20 | 800-1100 | 37×2 | 9051×4822×4785 | |
| 3 | 3600×8000 | 300 | 820 | 8-10 | 20 | 800-1100 | 45×2 | 9052×4822×5306 | |
| 3 | 4000×10000 | 300 | 820 | 8-10 | 23 | 1200-1800 | 45×3 | 9700×6310×5720 |
Projects
Vibrating Screen used in Aggregate Project of Hongsheng in Qingyuan, GuangdongVibrating Screen used in Aggregate Project in Yinkeng, Qingyuan, GuangdongVibrating Screen used in Wuzhou City Investment (Huaqun)’s Project in GuangxiVibrating Screen used in Changtou Jinrunyuan’s Project in Zhijiang, HubeiVibrating Screen used in Jintai Mining’s Project in JiangxiVibrating Screen used in Tianjing Calcium Company’s Project
For a metal ore beneficiation project, what role does the crushing and screening section play?
The crushing and screening section classifies run-of-mine ore into suitable size ranges, providing uniform feed for subsequent grinding or beneficiation processes and improving overall processing efficiency.
In a turnkey mobile crushing and screening solution, what modules are usually combined?
Feeding, crushing, screening, conveying, and electrical control modules are typically integrated to form an independent, mobile closed-circuit system.
For aggregate and mineral processing operations requiring high screening accuracy and stable operation, can vibrating screens meet these demands?
With multi-deck screen configurations and high-amplitude design, vibrating screens offer large processing capacity, high classification accuracy, robust structure, and stable operation, enabling efficient screening of aggregates and ores under continuous high-load conditions.
