3-way Wye Brass Ball Valve
Request a Quote
- Max. working pressure: W.O.G. (water, oil, inert gas):
- Unvented Valve: 600PSI@70°F
- Vented Valve: 250PSI@70°F - W.S.P. (working steam pressure):
- Unvented Valve: 150PSI@365°F
- Vented Valve: Not rated - Vacuum rating: 29" Hg
- Temperature range: -40 °F to 365 °F (-40 °C to 185 °C)
- Designed for the portable air compressor industry, these 3-way Wye brass ball valves control the flow of water, oil, and inert gases in two directions and are great for mixing and diverting.
Inch/Metric(mm)
| Item # | Inlet Size | Outlet Size | A1 (In) | C (In) | D (In) | E | F | ||||
| Inch | mm | Inch | mm | Inch | mm | Inch | mm | ||||
| MTW-7510 | 1" NPT Female | 3/4" NPT Male | 0.59 | 14.99 | 2.5 | 63.5 | 2.05 | 52.07 | 5.18 | 131.57 | 90 Degree |
| MTW-7550 | 1/2" NPT Female | 3/4" NPT Male | 0.39 | 10 | 2.54 | 64.5 | 2.01 | 51 | 4.8 | 122 | 90 Degree |
| MTW-5050 | 1/2" NPT Female | 1/2" NPT Male | 0.39 | 10 | 2.54 | 64.5 | 2.01 | 51 | 4.8 | 122 | 90 Degree |
| Part # | Part Name | Material |
| 1 | Body | Brass |
| 2 | Seat | PTFE |
| 3 | Ball | Brass |
| 4 | Cap | Brass |
| 5 | Stem | Brass |
| 6 | O-ring | Rubber |
| 7 | Handle | Steel |
| 8 | Nut | S.S |
| 9 | Handle | Steel |
