Automatic Vertical Can Body Necking Machine Manufacturer

Automatic Vertical Can Body Necking Machine

Request a Quote

View All: http://canbodymakingline.com/1-5-2-automatic-vertical-can-body-necking-machine.html

The ST-B31VA automatic vertical can body necking machine is used for the necking of large and round 3-piece cans. It will neck welded can bodies according to set proportions. Depending on different can sizes, it features a production capacity of up to 350 cans/min. It can also precisely control the stretching or dislocation of printed patterns on the can body caused by necking to ensure minimum change.

STWMF has over 60 years of experience in the design and production of necking machines. We provide automatic necking machines with various production capacities, ensuring we are able to meet the packaging requirements of beverage factories, beer factories, and food factories. factories.

Features

Vertical design, covering a small area and convenient for connection to the next process.
6 necking heads
High production capacity, max. 350 cans/min (depending on can size)
Central lubricating (underside) & manual lubricating(upside)

Parameters

Machine type	ST-B31VA
Necking head	6H
Range of can dia.	202D-401D
Range of can height	50-160 mm
Capacity per minute	Up to 350 cans/min (depend on can size)
Horse power required	2.2+0.75+0.18KW
Compress air Required	0.3MPa, 50 L/min
Floor space &overall height	2540×1250×1600 mm
Net weight	About 2500 kgs
Height of input station	800 mm
Lubricate	Central lubricating system(underside)& manual lubrication(upside)
Speed control	Inventer
