BOP Hydraulic Hose (Armoured) Type: BK3000/BK5000
Request a Quote
View All: http://tech-flexcn.com/1-7-3-2-bop.html
The BOP hydraulic hose is designed for pressure control of blowout preventers with an armored cover. The maximum working pressure reaches 5,000 PSI and maintains for up to 5 minutes in a 704℃ fire to ensure safe operation and emergency rescue.
Features:
Temperature Range:
-40℃ to + 121℃
Construction:
- Tube: Black nitrile rubber with excellent oil, seawater, acid and alkali resistance, thermal insulation
- Reinforcement: High strength helix steel wire
- Fire Insulation: Glass fiber cloth
- Cover: Black chloroprene rubber, fire resistance, abrasive and oil resistance, ozone resistance, anti-aging
- Armored Cover: Stainless steel retractable cover.
Technical Parameters:
BK3000 Series Technical Parameters:
| Code No. | Size (inch) | I.D. (mm) | O.D. (mm) | W.P. | B.P. | Safety factor | MBR (mm) | Weight (Kg/m) | LengthMax (m) | ||
| (bar) | (psi) | (bar) | (psi) | ||||||||
| BK3000-10 | 3/8 | 10 | 28 | 207 | 3000 | 828 | 12000 | 4.0 | 152 | 1.2 | 100 |
| BK3000-12.5 | 1/2 | 12.5 | 31 | 207 | 3000 | 828 | 12000 | 4.0 | 229 | 1.5 | 100 |
| BK3000-19 | 3/4 | 19 | 40 | 207 | 3000 | 828 | 12000 | 4.0 | 305 | 2.0 | 100 |
| BK3000-25 | 1 | 25 | 46.5 | 207 | 3000 | 828 | 12000 | 4.0 | 381 | 3.5 | 100 |
| BK3000-32 | 1-1/4 | 32 | 55 | 207 | 3000 | 828 | 12000 | 4.0 | 457 | 4.7 | 60 |
| BK3000-38 | 1-1/2 | 38 | 61 | 207 | 3000 | 828 | 12000 | 4.0 | 559 | 5.7 | 60 |
| BK3000-51 | 2 | 51 | 75 | 207 | 3000 | 828 | 12000 | 4.0 | 686 | 7.6 | 40 |
BK5000 Series
| Code No. | Size (inch) | I.D. (mm) | O.D. (mm) | W.P. | B.P. | Safety factor | MBR (mm) | Weight (Kg/m) | LengthMax (m) | ||
| (bar) | (psi) | (bar) | (psi) | ||||||||
| BK5000-10 | 3/8 | 10 | 28 | 345 | 5000 | 1380 | 20000 | 4.0 | 152 | 1.6 | 100 |
| BK5000-12.5 | 1/2 | 12.5 | 31 | 345 | 5000 | 1380 | 20000 | 4.0 | 229 | 2.0 | 100 |
| BK5000-19 | 3/4 | 19 | 40 | 345 | 5000 | 1380 | 20000 | 4.0 | 305 | 2.6 | 100 |
| BK5000-25 | 1 | 25 | 46.5 | 345 | 5000 | 1380 | 20000 | 4.0 | 381 | 3.7 | 100 |
| BK5000-32 | 1-1/4 | 32 | 55 | 345 | 5000 | 1380 | 20000 | 4.0 | 457 | 6.0 | 60 |
| BK5000-38 | 1-1/2 | 38 | 65 | 345 | 5000 | 1380 | 20000 | 4.0 | 559 | 7.1 | 60 |
| BK5000-51 | 2 | 51 | 80 | 345 | 5000 | 1380 | 20000 | 4.0 | 686 | 10.0 | 40 |
