Rotor Mill

Request a Quote

View All: http://finegrindingmill.com/1-7-rotor-mill.html

Using multi-layer grinding tools for grinding and grinding of agglomerates

Features a multi-layer grinding cutter head with strong shearing force and breaking force, ideal for breaking up agglomerates, grinding and drying water-containing materials, and grinding fiber materials
Particularly suitable for the dispersion and reduction of agglomerated materials such as calcium carbonate light, kaolinite, aluminum hydroxide, magnesium oxide, polyvinyl alcohol, PVC, PE, cellulose, and other heat-sensitive materials
Widely applicable in non-metallic mineral processing industries as well as chemical, fuel, feed, and food production processes
Particle size range D50: 3 ~ 45 μm

Technical Parameters

Parameter	400	600	800	1000	1200	1500
Grinding disc diameter (mm)	400	540	725	950	1150	1450
Grinding disc rotate speed (rpm)	4200	3050	2100	1850	1480	1250
Grinding disc linear speed (m/s)	87.5	86.7	79.8	92.0	89.1	94.9
Grinding disc power (kW)	30	45	75~90	110	132~160	200~250
Max. air flow (m³/h)	3000	4500	6000	7500	9000	12000

Note: The particle size, specific gravity, hardness, and moisture of raw materials are all closely associated to the production capacity. These parameters should only be used as a reference; for more detailed information please consult our engineers.
