Molded Inductor Testing & Packaging Machine
Request a Quote
Model: AM-CB-20
JDL molded inductor testing & packaging machine is an automatic equipment which performs electrical performance testing, appearance inspection and reel packaging of inductor products. This versatile machine is applicable to molded inductor, NR series inductor, CD series coil and more, just by changing different special parts. It features PLC control, intuitive human-machine operation interface, optional loading modes, reasonable structure, unmanned operation and high efficiency. Besides, the product model is customizable to customer needs.
Product Details:
Technical Parameters
| Feeder | Vibratory Bowl Feeder |
| Packaging Method | Automatically |
| Testing Project | Electrical performance test |
| Capacity | 4-12Kpcs/h |
| Application | Molded inductor, NR inductor |
| Control Method | PLC controlled |
| Temperature | -5℃-50℃ |
| Size(L*W*H) | L1200 * W780 * H1500mm |
| Power supply | Single phase AC220V/50HZ |
| Air supply | 0.4—0.7mpa |
| Power consumption | 2.5kW |
| Weight | About 350kg |
