Pelletizing Machine
Description
The supporting rod and the main shaft of LoChamp MZLH series biomass pelletizing machine are forged together. The supporting rod of the roll is abandoned, greatly improving the rigidity of the main shaft and roll. Compared with the traditional pelletizing machines, the output of our biomass pellet machine is increased by 10%-12%.
Automatic oiling is operated when this machine starts up. The oiling time and oiling volume can be set by users based on the oil quality and material conditions.
Application
MZLH series pelletizing machine can process thorough grainy treatment for different materials. It is mainly applicable to the production of biomass pellet with the main raw materials of sawdust, straw, stalk, rice husk, peanut shell, coconut shell, palm shell and other crop wastes, commercial crop wastes and wood materials. And it helps to maximum the benefits for our clients.
| Model | Motor power (kw) | Ring die speed (r/min) | Inner diameter of ring die and width of the rolling area (mm) | Roller diameter (mm) | Capacity (t/h) |
| MZLH25 | 2×11+0.75 | 422 | 250×75 | 104 | 0.2 |
| MZLH35A | 2×30+0.75 | 327 | 350×100 | 168 | 0.5 |
| MZLH42A | 2×55+0.75 | 340 | 420×138 | 204 | 1 |
| MZLH52A | 2×75+0.75 | 340 | 520×176 | 250 | 1.5 |
