135 Small Power Generator (24~200KW) Manufacturer

135 Small Power Generator (24~200KW)

Request a Quote

View All: http://jinanengine.com/3-1-Natural-Gas-4.html

HIGH QUALITY AND EFFICIENCY WIDE POWER RANGE

Description of 135 Small Power Generator

Rated rpm: 1500r/min;
Power supply mode: three-phase four-line;
Starting mode: manual starting/ 24DC starting;
Cooling mode: closed/semi open water cooled;
Gas consumption: ≤0.33m3/kW.h;
Heat consumption: ≤11500 kJ/ kW.h

Click Here to

Technical Specification of Small Power Generator

Set model		5 GFT 30GFT	40GFTA1	65GFTA1	80GF-Z	90GFTA1	120GFTA1 140GFTA1
Type		natural gas			biogas	natural gas
Engine model		Q1100D Q4135D	Q4135AD1	Q6135AD1	Q6135Z	Q6135DR1	Q6140DR1 Q12V135DA1
Rated power(kW)		5 30	40	65	80	90	120 140
Rated rev(r/min)		1500
Rated voltage(V)		400
Rated current (A)		9 54	72	117	144	162	216 252
Rated frequency(Hz)		50
Power factor		0.8
Power supply		three-phase four-line
Excitation		brushless
Starting mode		manual starting/ 24DC starting
Cooling mode		closed water cooled			semi-open	closed water-cooled
Heat consumption		≤11500 kJ/kw·h				≤11500 kJ/kw·h
Gas consumption		≤0.33m3/kW.h				≤0.33 m3/kW.h
Outline dimensions	Length(mm)	1400 2420	2420	3000	3000	3000	3200 3550
	Width(mm)	580 900	900	900	900	900	900 1150
	Height(mm)	720 1500	1500	1500	1500	1500	1500 1650
Net weight (kg)		350 2120	2120	2410		2530	2600 3200

CNPC JICHAI was formed in 1920, we are a prestigious brand in China and is a global leader in internal conbustion engine and generator set manufacturing. Our power solutions are designed to improve your performance and productivity.
