Vortex Flow Meter
Request a Quote
Vortex flow meters are a well established flow technology for liquid, steam and gas applications. They can offer an accurate and cost-effective metering solution, so that they are the preferred product for oilfield and city natural gas metering and trade metering at present. Our company adopts advanced investment casting technology, which is integral casting without welding.
Working Environment
- Temperature Rating: -30℃- 55℃
- Relative Humidity: 5%-95%
- Pressure rating: 86KPa-106KPa
- Medium Temperature Range: -20℃- 70℃
- Nominal Pressure: 1.6/2.5/4.0/6.3MPa
Specifications
| Size DN (mm) | Flow Rate (m3/h) | Operating Pressure (MPa) | Accuracy | Dimension (mm) |
| 15 | 1.0-10 | 1.6 2.5 4.0 6.3 10 16 | 1.0 1.5 | 162 |
| 20 | 1.5-15 | 162 | ||
| 25 | 3.0-30 | 182 | ||
| 32 | 6.0-60 | 200 | ||
| 40 | 7.0-70 | 233 | ||
| 50 | 12-150 | 300 | ||
| 80 | 40-400 | 330 | ||
| 330 | ||||
| 100 | 60-650 | 410 | ||
| 150 | 150-1500 | 516 | ||
| 200 | 240-3600 | 1.6;2.5;4.0 | 700 |
