Frozen Meat Dicing Machine
The frozen meat dicing machine is designed to dice pork, lamb, beef, chicken, and other meat products into uniform cubes of various sizes (from 1 to 60 mm, selectable at will).
The dicing machine is equipped with a mechanism that applies the right pressure to keep the blades securely tensioned, making the installation process and cutting adjustments easy. The entire dicing machine is built from 304 stainless steel and food-grade plastics, fully compliant with HACCP standards.
-
- Beef dicing
-
- Pork dicing
-
- Chicken dicing
Key Parameters
| Model | HKDQJ300 |
| Voltage | 380V |
| Power | 3kW |
| Production capacity | 500-1000 kg/h |
| Dimensions | 1380 × 750 × 1060 mm |
| Cutting grid size | 1, 3, 4, 5, 6, 7, 8, 10, 12, 16, 24, 30, 60 mm (selectable by user) |
| Cutting groove size | 84 × 84 × 350 mm / 120 × 120 × 550 mm |
Features
-
Upgraded discharge port: Made from a single piece of food-grade polyethylene, offering low wear and easy replacement.
-
Precision gear and belt drive: Ensures smooth, constant-speed rotation of the cutting disc. The machine automatically adjusts blade speed based on frozen meat hardness and cutting requirements, improving efficiency while reducing energy consumption and mechanical wear.
-
Stainless-steel cutting blades: Manufactured from premium, thickened stainless-steel alloy; extremely sharp with excellent cutting performance.
