Double Sided Brush Sanding Machine (Left and Right)
Request a Quote
Mingda’s double sided brush sanding machine (left and right) is equipped with a durable sanding brush to simultaneously complete brush sanding processes on different irregular wooden workpieces, particularly long strip workpieces. It is primarily used to sand wooden materials before painting, and thus ensure a fine, smooth surface. PLC controlled, it is easy to operate and adjust, ensuring it is applicable to an array of different wood materials.
Main components of the brush sanding machine are sourced from international suppliers with a high quality and exceptional stability and safety, including a Zei Hua taper sanding motor, Taiwan Mei Na rubber roller, Schneider, France, electrical elements, and Rexroth, German, frequency converter.
Specification| Model | MD-2P-S |
| Spindle horsepower | 1.5KW×2 |
| Feeding horsepower | 180W×4 |
| Feeding speed(inverter speed) | 6-15m/min |
| Minimum sanding length | 370mm |
| Maximum sanding width | 100mm |
| Maximum sanding height | 100mm |
| Vacuuming mouth size | 4 inch×2 |
| Mechanical dimensions(L×W×H) | 1450×930×1150mm |
| Machine weight | 350KG |
