ST608W Wheel Excavator
Request a Quote
Hydraulic wheel excavator compatible with log grapples, buckets, breakers, and other attachments for forestry, construction, and municipal projects
- Operating weight
5100kg - Rated load
1500kg - Bucket capacity
0.6m³ - Max. speed
12/18km/h
The ST608W dual-drive wheel excavator is equipped with both front and rear wheel drive, ensuring strong traction and stability. It features a two-way telescopic steering system, four-wheel air brake, and an oversized brake hub for safe and responsive control. The high-efficiency transmission system, enhanced power configuration, extended wheelbase, and low-stress high-strength welded box-type frame work together to provide superior durability and handling. The enlarged and lengthened boom and arm allow deeper excavation, while its climbing performance and overall efficiency rival those of imported models.
Specifications
| Operating Range | |
| Boom length | 3030mm |
| Arm length | 1860mm |
| Max. digging reach | 6000mm |
| Max. digging depth | 3380mm |
| Max. digging force | 45kN |
| Max. digging height | 5800mm |
| Max. dumping height | 4300mm |
| Tail swing radius | 1775mm |
| Dimensions | |
| Distance from arm to rotating center | 3620mm |
| Transport dimensions (L×W×H) | 5500×2100×2850mm |
| Ground clearance of counterweight | 1060mm |
| Min. ground clearance | 200mm |
| Technical Parameters | |
| Angle of rotation | 360° |
| Machine weight | 6000kg |
| Engine model | 498BPG (high configuration) |
| Hydraulic system working pressure | 19.5MPa |
| Rated power | 48kW |
| Travel speed (low/high) | 9/36km/h |
| Max. traction force | 60kN |
| Ground pressure | 52kPa |
| Grade climbing ability | 30° |
| Full swing cycle time | 5.5s |
| Bucket capacity | 0.2-0.3m³ |
| Swing overload pressure | 11MPa |
| Fuel consumption | 4L/h |
| Fuel tank capacity | 130L |
| Hydraulic tank capacity | 110L |
Features
- Enhanced safety design: The brake chamber is positioned behind the front axle to reduce the risk of damage from falling debris and ensure safer operation.
- Reliable transmission system: The transfer case is equipped with an internal oil pump, minimizing collision risk and enhancing operational reliability.
- Reinforced boom cylinder support: Strengthened mounting design prevents cracking during continuous heavy-duty work.
Optional attachments
- Log grapple
- Hydraulic grab
- Multi-tine grapple
- Hydraulic breaker
