Description
15kV cold shrink terminations and cable joints are made of high quality liquid silicone rubber and can be used for indoor and outdoor single core and 3-core cables since they provide good electrical insulation, resistance tracking and high elasticity. The applicable voltage is up to 15kV.
| Type | Size | Cable range(mm2) | |
| 8.7/15kV XLPE cable(1 core) | Indoor termination | 8.7/15kVCDLN-1/1 | 25-50 |
| 8.7/15kVCDLN-1/2 | 70-120 | ||
| 8.7/15kVCDLN-1/3 | 150-240 | ||
| 8.7/15kVCDLN-1/4 | 300 | ||
| 8.7/15kVCDLN-1/5 | 400 | ||
| 8.7/15kVCDLN-1/6 | 500 | ||
| 8.7/15kVCDLN-1/7 | 630 | ||
| 8.7/15kVCDLN-1/8 | 800 | ||
| 8.7/15kV XLPE cable(1core) | Outdoor termination | 8.7/15kVCDLW-1/1 | 25-50 |
| 8.7/15kVCDLW-1/2 | 70-120 | ||
| 8.7/15kVCDLW-1/3 | 150-240 | ||
| 8.7/15kVCDLW-1/4 | 300 | ||
| 8.7/15kVCDLW-1/5 | 400 | ||
| 8.7/15kVCDLW-1/6 | 500 | ||
| 8.7/15kVCDLW-1/7 | 630 | ||
| 8.7/15kVCDLW-1/8 | 800 | ||
| 8.7/15kV XLPE cable(1core) | Straight joint | 8.7/15kVCDLJ-1/1 | 25-50 |
| 8.7/15kVCDLJ-1/2 | 70-120 | ||
| 8.7/15kVCDLJ-1/3 | 150-240 | ||
| 8.7/15kVCDLJ-1/4 | 300 | ||
| 8.7/15kVCDLJ-1/5 | 400-500 | ||
| 8.7/15kVCDLJ-1/6 | 630-800 | ||
| 8.7/15kV XLPE cable(3 core) | Indoor termination | 8.7/15kVCDLN-3/1 | 25-50 |
| 8.7/15kVCDLN-3/2 | 70-120 | ||
| 8.7/15kVCDLN-3/3 | 150-240 | ||
| 8.7/15kVCDLN-3/4 | 300-400 | ||
| 8.7/15kVCDLN-3/5 | 500-630 | ||
| 8.7/15kVRSWY-3/5 | 500-630 | ||
| 8.7/15kV XLPE cable(3 core) | Outdoor termination | 8.7/15kVCDLW-3/1 | 25-50 |
| 8.7/15kVCDLW-3/2 | 70-120 | ||
| 8.7/15kVCDLW-3/3 | 150-240 | ||
| 8.7/15kVCDLW-3/4 | 300-400 | ||
| 8.7/15kVCDLW-3/5 | 500-630 | ||
| 8.7/15kV XLPE cable(3 core) | Straight joint | 8.7/15kVCDLJ-3/1 | 25-50 |
| 8.7/15kVCDLJ-3/2 | 70-120 | ||
| 8.7/15kVCDLJ-3/3 | 150-240 | ||
| 8.7/15kVCDLJ-3/4 | 300 | ||
| Standard | IEC 60502 | |
| Voltage classes | 8.7/15kV | 8.7/15kV |
| Partial discharge test at ambient temperature | 15kV, < 10pC | 15kV, < 10pC |
| AC withstand voltage test | 39kV 5min | 39kV 5min |
| Impulse voltage withstand | ±95kV each polarity 10 times | ±95kV each polarity 10 times |
