36kV Cold Shrink Cable Terminations and Joints
Request a Quote
- Cold Shrink Terminations
- Cold Shrink Cable Joints
Description
36kV cold shrink terminations and cable joints are made using high quality liquid silicone rubber and can be used for indoor and outdoor single core and 3-core cables due to good electrical insulation, resistance tracking and high elasticity. The applicable voltage is up to 36kV.
| Type | Size | Cable range(mm2) |
| 36Kv indoor termination for 1-core | 35kVCDLN-1/1 | 50-120 |
| 35kVCDLN-1/2 | 150-240 | |
| 35kVCDLN-1/3 | 300-630 | |
| 36Kv outdoor termination for 1-core | 35kVCDLW-1/1 | 50-120 |
| 35kVCDLW-1/2 | 150-240 | |
| 35kVCDLW-1/3 | 300-630 | |
| 36Kv straight joint for 1-core | 35kVCDLJ-1/1 | 50-120 |
| 35kVCDLJ-1/2 | 150-240 | |
| 35kVCDLJ-1/3 | 300-630 | |
| 36Kv indoor termination for 3-core | 35kVCDLN-3/1 | 50-95 |
| 35kVCDLN-3/2 | 120-185 | |
| 35kVCDLN-3/3 | 240-400 | |
| 36Kv outdoor termination for 3-core | 35kVCDLW-3/1 | 50-95 |
| 35kVCDLW-3/2 | 120-185 | |
| 35kVCDLW-3/3 | 240-400 | |
| 36Kv straight joint for 3-core | 35kVCDLJ-3/1 | 50-95 |
| 35kVCDLJ-3/2 | 120-185 | |
| 35kVCDLJ-3/3 | 240-400 |
| Standard | IEC 60502 | |
| Voltage classes | 18/36kV | 18/36 kV |
| Partial discharge test at ambient temperature | 45kV, < 10pC | 45kV, < 10pC |
| AC withstand voltage test | 117kV 5min | 117kV 5min |
| Impulse voltage withstand | ±200kV each polarity 10 times | ±200kV each polarity 10 times |
