The KTM410 automatic window-patching machine is used to open window and patch the film on a variety of international and domestic standard envelopes and flat bags. This model can also be attached to different machines, including the BW292 Model, POCKET124 Model, or POCKET135 Model to produce different window envelopes. The KTM410 is known for its high efficiency, stable functions, easy operation, quick adjustments and space saving structure, making it ideal for mass production jobs.

Major Structural Features
Using a suction method at the lower portion of the machine, blank paper that is laid on the feed plate is fed into machine. This method allows the pile of blanks to be replenished while the machine is operating, and no extra downtime. The paper orientation unit works with both convenience and accuracy while the lateral and longitudinal folding units help add to the overall quality of the products. Rotary glue applying unit meets the requirements of glue tracks of any shape, and assisted by the suction cylinder, the folding unit works in a stable manner. A graduated disk accurately and directly shows the adjustment volume, while the collection unit is equipped with an electronic counting and batching system.

Illustration of Function

For product changes, Without notice.

Specifications
Technical Info KTM410 TM410
Max.Paper Blank Size (mm) 410×350 410×350
Window Length (mm) 35-140 35-140
Window Width (mm) 15-120 15-120
Window Die Cutting in no
Max. Patching size (mm) 140×160 140×160
Min. Patching size (mm) 35×55 35×55
Paper Weights Ca (gsm) 80-120 80-120
Total Power (kW) 4.5 4.1
Max. Speed (pcs/h) 11000 12000
Machine Weight (kg) 3000 2300
Machine Size  (L×W×H)(m) 3500×1090×1720 3200×1090×1720
