Multipurpose Road Maintenance Truck

Request a Quote

Website: http://sgroadmachine.com/2019/5-7-multipurpose-road-maintenance-truck.html

Multipurpose road maintenance trucks are specialized equipment for special operations. They use a single generator and hydraulic transmission, with the generator providing power for all operations, including traveling, and ensures normal operation under any conditions.

Parameters of Multipurpose Road Maintenance Truck HGY5150TYH:

No	Parameter	Unit	Standard Details	Reference
1	Chassis Weight	kg	15800
2	Chassis Generator	kw	139
3	Highest Speed	km/h	98
4	Maximum Lift Capacity of Kunckle Boom Crane	kg	3200
5	Maximum Engine Power	kw	23.5
6	Maximum Rear Tractive Force	kg	5000
7	Covering Radius of Illuminating Lamp	m	35～50
8	Maximum Lifting Weight for Self-Discharging	kg	6000
9	Loading Capacity of the Compartment	kg	5000
10	Maximum Pressure of Compressed Air	MPa	1.25
11	Maximum Nominal Flow Rate of Compressed Air	m3/min	0.6
12	Lowest Travelling Speed	km/h	0.5～1	Stepless Speed Control
13	Maximum Power Output for the Side and Rear Part	kw	Three-Phase: 7.5 Single Phase: 2
14	Maximum Hydraulic Power for the Front Part	kw	15
15	Maximum Hydraulic Power for the Medium and Rear Part	kw	20
16	Dimension	mm	810×2470×3080

Chassis （FAW Jie Fang Chassis)

High Traction
High load
Comfortable Drive

Work System:

Stepless speed control is achieved using a hydraulic low speed power transmission case, thus allowing the multipurpose road maintenance truck to drive event at super low speed (0.5-1 km/h) to meet the requirements for special operations.
With 360°rotation and maximum work range of 6.6m, the maximum lifting weight of the knuckle boom crane is 3200Kg.
When operating in low light environments, the light source height is 4m, and covers a radius of 35 to 50 meters.
The compressed air control system is able to generate compressed air with a maximum pressure of 1.25Mpa and maximum nominal flow rate of 0.6m3/min, allowing the compressed air control system to be used as a pneumatic power tool.
With stable and reliable operation, most movement of this multipurpose road maintenance truck is achieved through hydraulic control.
