Copper Connector (without barrier), GT-G Series
Request a Quote
GT-G series copper cable lug (straight through lug) can be used to connect the electric wire, the power cable and the electrical equipment of a power distribution. It can also be used with cold and heat shrink outdoor termination kits.
Download
Features
The cable lug is made of quality T2 copper rods, with a copper content ≥99.0% and good conductivity performance (conductivity rate ≥98% IACS). The raw copper material meets the national standard of GB/T 5231-2001.
Structure Chart
Specifications
| Model | Main dimensions | ||
| Outer dimension D | Inner dimension d | Length L | |
| GT-G-10 | 8 | 5.0 | 50 |
| GT-G-16 | 9 | 6.0 | 56 |
| GT-G-25 | 10 | 7.0 | 60 |
| GT-G-35 | 12 | 8.0 | 64 |
| GT-G-50 | 14 | 10.0 | 72 |
| GT-G-70 | 16 | 12.0 | 78 |
| GT-G-95 | 18 | 13.0 | 85 |
| GT-6-120 | 20 | 15.0 | 90 |
| GT-G-150 | 22 | 16.0 | 94 |
| GT-G-185 | 25 | 18.0 | 100 |
| GT-G-240 | 27 | 20.0 | 110 |
| GT-G-300 | 31 | 24.0 | 120 |
| GT-G-400 | 34 | 26.0 | 135 |
| GT-G-500 | 38 | 30.0 | 150 |
| GT-G-630 | 45 | 35.0 | 170 |
