Multi-DiscFilter
The multi-disc filter is widelyused in waste paper recycling system and paper making industry.
Features
Through the filtering of white water, the recyclingrate of fibers is pretty high.
Specificationsof Multi-Disc Filter
Through the filtering of white water, the recyclingrate of fibers is pretty high.
Specificationsof Multi-Disc Filter
| Model | ZNP36 | ZNP45 | ZNP56 |
| Filtering Disc Dia(mm) | 3600 | 4500 | 5600 |
| Filtering Disc Number | 6~16 | 8~20 | 10~20 |
| Filtering Area(mm2) | 15 | 25 | 38 |
| Motor Power(KW) | 7.5~15 | 15~18.5 | 22~37 |
| Stock Type | OCC pulp and chemical pulp | Deinking pulp and grass pulp | Water |
| Inlet Consistency(%) | 0.5~0.8 | 0.5~1.0 | 0.3~0.5 |
| Outlet Consistency(%) | 12(adjustable) | 5~10(adjustable) | 3.5~49(adjustable) |
| Capacity(t/24h) | 0.7~1.1 | 0.5~0.7 | 1.6~2.8 |
