Diesel Forklift

Request a Quote

Website: http://sutemachinery-en.com/6-2-diesel-forklift.html

Specifications

Model	CPCD30	CPCD35	CPCD50	CPCD80
Power type	Diesel	Diesel	Diesel	Diesel
Rated load capacity	3000kg	3500kg	5000kg	8000kg
Load center distance	500mm	500mm	500mm	600mm
Driving mode	Seated	Seated	Seated	Seated
Overall length (with forks)	3925mm	3861mm	4075mm	4990mm
Overall length (without forks)	2780mm	2850mm	3055mm	3470mm
Overall width	1225mm	1225mm	1380mm	1980mm
Mast height (lowered)	2140mm	2140mm	2205mm	2240mm
Overhead guard height	2100mm	2110mm	2215mm	2380mm
Max. working height	4262mm	4262mm	4290mm	4210mm
Wheelbase	1810mm	1810mm	1950mm	2330mm
Front overhang	441mm	441mm	480mm	550mm
Rear overhang	549mm	607mm	575mm	600mm
Front wheel track width	1000mm	1000mm	1080mm	1500mm
Rear wheel track width	980mm	980mm	985mm	1750mm
Min. Ground clearance	165mm	165mm	165mm	200mm
Min. Turning radius	2520mm	2580mm	3250mm	3200mm
Standard lifting height	3000mm	3000mm	3000mm	3000mm
Mast tilt angle (front/rear)	6°/12°	6°/12°	N/A	6°/12°
Free lift height	260-1100mm	260-1100mm	N/A	300-1845mm
Max. lifting speed (unloaded)	480mm/s	480mm/s	400mm/s	380mm/s
Max. lifting speed (loaded)	440mm/s	370mm/s	300mm/s	340mm/s
Max. travel speed (unloaded)	20km/h	20km/h	22km/h	22km/h
Max. gradeability (loaded)	20%	20%	15%	20%
Total machine weight	4170kg	4470kg	5710kg	9950kg
Tire type	Pneumatic tires	Pneumatic tires	Pneumatic tires	Pneumatic tires
Tire size (front)	28×9-15	28×9-15	300-15	8.25-15-16
Tire size (rear)	6.50-10	6.50-10	700-12	8.25-15-16
Braking system (driving)	Hydraulic	Hydraulic	Hydraulic	Hydraulic
Braking system (parking)	Mechanical	Mechanical	Mechanical	Mechanical
Engine model	Xinchai	Xinchai	Xinchai	Xinchai
Engine power	36.8kW	36.8kW	36.8kW	110kW

Features

Meets the latest EC and EPA emission standards, delivering strong performance with lower environmental impact.
The high-efficiency hydraulic system precisely matches power to working demand, minimizing energy loss and reducing fuel costs.
The mast damping structure reduces impact and vibration, while the sound-insulated cabin design ensures smooth and quiet operation.
Designed with operator comfort in mind, the power-assisted braking system reduces pedal effort, the right-hand control lever allows smoother handling, and the dual-switch setup keeps operation intuitive and effortless.
