280G-F

These premade pouch packaging machines are designed to work with various types of pouch formats, such as stand-up pouches, pouch-in-pouch packs, eight-side-seal designs, with a filling capacity of up to 3000ml. They are equipped with an automatic pouch feeder with a hand-like separation system that can pick and separate even laminated pouches that tend to stick together, keeping feeding smooth and reliable. Thanks to their stable output of about 45 pouches per minute, these filling and sealing system fit well for products such as chocolate, high-grade tea, specialty nuts, and cosmetics. The components that touch the product are made of high-quality stainless steel, which makes them easy to clean, resistant to corrosion, and suitable for meeting the hygiene requirements of food and pharmaceutical production.

Process Flow
  • Pouch loading
  • Pouch pick-up
  • Pouch opening detection
  • Bottom opening
  • Filling
  • Pouch spreading
  • Heat sealing
  • Seal cooling
  • Finished pouch forming
  • Finished pouch discharge
Specifications
Model 280G-F
Pouch size range (Min.) 120×140mm (Max.) 280×400mm
Max. filling volume 3000ml
Packaging speed ≤45
Machine dimensions (L × W × H) 3200×2600×1500mm
Machine weight 1500kg
Installed power 5.5kw
Air consumption 450L/min
Optional Functions

Zipper opening

Pouch hole punching

  • Sombrero hole (butterfly hole)
  • Round hole
  • Special-shape punching
  • Arc hole / Curved slot hole
  • Euro hole

Coding options

  • Hot stamp coding
  • Inkjet printing
  • Laser marking

Sealing patterns

  • Grid pattern
  • Dotted pattern
  • Plain/flat pattern
  • Vertical rib pattern
Details
Customer Case Studies

In 2025, a food producer based in Hohhot added our 3000ml 1-nozzle fillinf premade pouch packaging machine to its line for packing 282 g cheese sticks in flat pouches. The pouch packaging equipment was chosen to ensure stable filling, clean sealing, and a neat final presentation for this high-volume retail product.

Stand-up pouches (Doypack) and zipper pouches are widely used because they stand upright, look clean and modern on the shelf, and are easy for consumers to open, pour from, and reseal for repeated use.
