CNC Wood Cutting Machine

Request a Quote

View All: http://woodmachines-en.com/1-4-1-cnc-wood-cutting-machine.html

//Woodworking Machinery

CNC wood mill cutter for shaping components of chairs, tables, doors and other furniture

Woodworking Machinery

Air pressure0.4-0.9MPa
Blade sizeØ5-10mm
Total power15.0kW
Machine weight1600kg

The CNC wood cutting machine is designed for high-precision cutting of wood panels and solid wood into furniture parts or semi-finished components. It handles a wide variety of shapes and sizes, including wardrobe side panels, cabinet doors, table tops, and legs. The system supports both standard and custom profiles, enabling flexible production that meets the diverse design requirements of modern furniture. With reliable cutting accuracy and automated operation, the wood mill cutter ensures consistent quality and improved efficiency for large-scale and custom manufacturing of furniture components.

Specifications

Max. working thickness150mm
Max. working width1300mm
Max. working length2000mm
Main spindle speed18000r/min (2pcs)
Main spindle power2×7.5kW
Dust suction inlet diameterØ98 (2pcs)
Air pressure0.4-0.9MPa
Blade sizeØ5-10mm
Total power15.0kW
Servo systemInter lake
Machine weight1600kg
Machine dimensions (L×W×H)3400×2300×1600mm

Sample Showcase
